Мосты диодные KBPC

Наименование	V_RRM В	V_RMS В	V_DC В	I_O А	I_FSM А	V_F В	I_R25	I_R	I²t	C_J	R_qJC
KBPC2510	1000	700	1000	25	400	1.1	10	500	664	300	2.2
KBPC35005	50	35	50	35	400	1.1	10	500	664	300	2.2
KBPC3501	100	70	100	35	400	1.1	10	500	664	300	2.2
KBPC3502	200	140	200	35	400	1.1	10	500	664	300	2.2
KBPC3504	400	280	400	35	400	1.1	10	500	664	300	2.2
KBPC3506	600	420	600	35	400	1.1	10	500	664	300	2.2
KBPC3508	800	560	800	35	400	1.1	10	500	664	300	2.2
KBPC3510	1000	700	1000	35	400	1.1	10	500	664	300	2.2
KBPC5010	1000	700	1000	50	400	1.1	10	500	664	300	2.0

Maximum Recurrent Peak Reverse Voltage	V_RRM
Maximum RMS Bridge Input Voltage	V_RMS
Maximum DC Blocking Voltage	V_DC
Maximum Average Forward Rectified Output Current at Tc = 55°C	I_O
Peak Forward Surge Current 8.3 ms single half sine-wave superimposed on rated load (JEDEC Method)	I_FSM
Maximum Forward Voltage Drop per element at 25A DC	V_F
Maximum DC Reverse Current at Rated	I_R
DC Blocking Voltage per element
I²t Rating for Fusing (t<8.3ms)	I²t
Typical Junction Capacitance ( Note1)(Тип. сопротивление перехода(справ.))	C_J
Typical Thermal Resistance (Note 2)(Тип. тепловое сопротивление(справ.))	R_qJC
Operating and Storage Temperature Range (Рабочая температура и температура хранеия)	T_J,T_STG
